JUKI LG-158-FU TWIN NEEDLE UNISON 6.4mm FEED LONG ARM HEAD ONLY
Description / JUKI LG-158-FU TWIN NEEDLE UNISON 6.4mm FEED LONG ARM HEAD ONLY
Juki LG-158-FU
2-Needle Unison-feed, Long Arm Lockstitch Machine with Vertical-axis Large Hook
With a generous 750 mm of free space under the arm and powerful unison-feed that provides a maximum stitch length of 10 mm, the machine delivers outstanding productivity when sewing heavy materials such as tents and sheets.
The machine head structure is designed to improve operability
With its 750 mm wide space under the arm and a handwheel mounted at the middle of arm, the machine is ideal for the sewing of heavy materials such as tents and sheets. A large material can be sewn while spread over the bed.
The bobbin winder is installed at the front face of the arm for easy operation.
The presser foot goes up as high as 21.5 mm to ensure easy placement/removal of extra heavy-weight materials.
Safety device protects the needle and hook from damage
If the thread gets caught in the hook, the safety device is automatically actuated, preventing possible hook damage. Pressing the reset button will immediately return the machine to the normal state.
Consistent seam quality
With its unison feed mechanism that ensures a smooth and steady feed of materials, the machine provides consistent seam quality with no material slippage. Eleven different kinds of needle gauges are prepared for the LG-158. The most suitable gauge for the current machine use can easily be selected.
The frequency of bobbin thread replacement is reduced
Since the machine incorporates a vertical-axis large hook, the frequency of bobbin thread replacement is reduced, further increasing efficiency.
Technical Specification
| Model | Juki LG-158 |
|---|---|
| (2-needle) | |
| Max. sewing speed | 1,500sti/min* |
| Max. stitch length | 10mm (normal/reverse feed) |
| Needle bar stroke | 46.9mm |
| Needle gauge | Standard 19.1mm (3/4") |
| Lift of the presser foot | By pedal: 21.5mm |
| Thread take-up | Side type |
| Alternating vertical movement | 6mm~19mm |
| Hook | Vertical-axis large hook |
| Needle (at the time of delivery) | DD×1 (#25) |
| Thread | #20~#5, B69~B138, Nm=40/3~20/3 |
| Safety mechanism | Provided as standard |
| Bobbin winder | Built on the machine arm |
| Lubrication | By an oiler |
| Lubricating oil | JUKI New Defrix Oil No.1 (equivalent to ISO VG7) |
| Distance from needle to machine arm | 750mm |
| Bed size | 1,088mm×230mm |
| Weight of the machine head | 108kg |
*sti/min is the abbreviation for “stitches per minute”
