JUKI TSC-441 UNISON FEED CYLINDER ARM HEAD ONLY
Description / JUKI TSC-441 UNISON FEED CYLINDER ARM HEAD ONLY
Juki TSC-441
1-needIe, Semi-long Cylinder Bed, Lockstitch Machine with a Large Shuttle-hook for Extra-heavy-weight Materials (Unison feed)
A top & bottom feed mechanism has been added to the machine's needle feed system.This ensures a higher feed efficiency and the production of higher-quality seams without uneven material feed.
Use: Bags, pouches, shoes, seat belts, etc.
TSC-441U (Unison feed)
A top & bottom feed mechanism has been added to the machine's needle feed system.This ensures a higher feed efficiency and the production of higher-quality seams without uneven material feed.
Use: Bags, pouches, shoes, seat belts, etc.
Higher lift of the presser foot
The lifting range of the presser foot is as high as 20mm for smooth placement/removal of extra-heavy-weight materials.
Frequency of bobbin thread replacement is reduced
The machine comes with a large shuttle-hook. This type of shuttle-hook helps to reduce the frequency of bobbin thread replacement and is best suited for the sewing of extra-heavy-weight materials sewn with lower-count threads.
The bobbin winder is built into the front portion of the machine
The bobbin winder is built into the front portion of the machine arm for easy manipulation.
Wider space under the machine arm
The machine has a wider free space under the machine arm to allow the operator to easily place and remove a large sewing products. In addition, the machine has outstanding capabilities in the sewing of sharp curves.
Technical Specification
| Model name | Juki TSC-441U |
|---|---|
| Feed system | Unison feed |
| Max. sewing speed | 800sti/min* |
| Max. stitch length | 11mm (normal/reverse feed) |
| Needle bar stroke | 56mm |
| Lift of the presser foot | By pedal : 20mm/By hand : 12mm |
| Alternating vertical movement | 4~8mm |
| Thread take-up | Cam-type |
| Hook | Large shuttle-hook |
| Needle | 794 Nm130~Nm280 (standard Nm230) |
| Thread | #8~#0 (Japanese yarn count) |
| Lubrication | By hand |
| Free space for sewing | 420mm |
| Cylinder bed diameter | φ81mm |
| Weight of the machine head | 56kg |
*sti/min is the abbreviation for “stitches per minute”
More Information
| Part No | JUKITSC441 |
|---|---|
| Weight (KG) | 62.000000 |
| Manufacturer | Juki |
