JUKI PS-800-SB-8045-ZNZ 800MM X 450MM PATTERN SEAMER
Description / JUKI PS-800-SB-8045-ZNZ 800MM X 450MM PATTERN SEAMER
Juki PS-800-SB-8045-ZNZ
Pattern Seamer for Light-Weight Materials (800mm x 450mm Sewing Area) (with RFID and without knife)
The dry head machine achieves max. speed 3,000sti/min with supporting various sewing and materials.
Your Ingenuity creates opportunities for Automation.
Feeding type and sewing area
Space-saving PS-800-8045, 6045
The PS-800-8045, 6045 can be installed in a space-saving manner. Not only the parts department but also sewing lines can be used. (The table size of PS-800-8045 width is 1,200mm width, the same as 1-needle lockstitch machine. The PS-800-6045 table size is 1,560 mm width.)
Patterns are identified by means of RFID/Barcode reader to enable automatic reading of sewing data
Sewing patterns are automatically identified by means of RFID/ Barcode reader to automatically call up the relevant sewing program, thereby starting sewing quickly.
*RFID (radio frequency identification): It is the technology to read and write data saved on IC chips through wireless non-contact transfer of radio frequency waves and is used to identify and manage products.
Operation panel
The sewing pattern data format are supports DXF, AI, PLT, and DST. Sewing pattern data in these formats are widely used in many sewing plants. As a result, the operation panel is able to use the customers’ existing sewing pattern data immediately. As many as 999 sewing patterns can be saved on the large-capacity memory of the operation panel. (Editing software is included with the accessory.)
Oil stains are prevented
The machine head has adopted the advanced dry technology (no lubrication is required). Only the hook needs lubrication. The dry head is very effective when sewing materials on which oil stains are likely to spread such as those for down jackets.
Cloth trimmer specifications
The cloth trimmer comes in two different knives and a laser.
Rotary knife
This knife is suited to the sewing products designed to have straight portions and curve portions.
Laser cutter
This lazer is suited to soft materials such as knit.
Height of the intermediate presser at its lower dead point can be adjusted on the operation panel
It is possible to change the intermediate presser height at its lower dead point steplessly during sewing. This feature is particularly effective when sewing multi-layered portions of material. Since the material is stably held by the intermediate presser, sewing troubles such as stitch skipping and thread breakage are prevented.
Technical Specification
| Model name | Juki PS-800-SB-8045 |
|---|---|
| Application | Light-Weight Materials |
| Sewing area | 800 mm × 450 mm |
| Feeding type | Double stepping motor Belt Drive |
| Max. sewing speed | 3,000 sti/min* |
| Stitch length | 0.5 - 12.7 mm |
| Hook | Full-rotary double-capacity hook |
| Lift / Stroke of intermediate presser | Lifting amount: 20 mm / Stroke: Standard 4 mm |
| Variable lower position of the intermediate presser | DB × 1 #8M (7#~14#) |
| Storage of pattern data in the memory | Max. 999 patterns (80,000 sti/pattern) |
| Number of Indentifiable patterns | 999 patterns |
| Program input mode | 999 patterns |
| Program input mode | USB |
| File format | Convert DXF / AI / PLT / DST format to SLW format with editing software |
| Weight | 450Kg |
| Dimensions | 1,200mm (W)× 1,325mm (L)× 1,250mm (H) |
*sti/min is the abbreviation for “stitches per minute”
More Information
| Part No | JUKIPS800SB8045ZNZ |
|---|---|
| Manufacturer | Juki |
