JUKI MH-481-54U S/N CHAINSTITCH WITH AUTO UBT BOTTOM FEED SINGLE NEEDLE DOUBLE CHAIN

Part No JUKIMH48154U
Juki MH-481-54U 1-needle, Double Chainstitch Machine (with automatic thread trimmer)
Pricing and Availability on Request
Contact Us for Quote

Description / JUKI MH-481-54U S/N CHAINSTITCH WITH AUTO UBT BOTTOM FEED SINGLE NEEDLE DOUBLE CHAIN

Juki MH-481-54U

1-needle, Double Chainstitch Machine (with automatic thread trimmer)

The machine comes with a silicon oil lubricating unit, thread spreading mechanism and thread trimming mechanism which trims the thread without fail, thereby consistently ensuring beautifully-finished seams for light- to medium-weight materials.

The machine is provided with mechanisms to enable upgraded sewing

The machine comes with a thread spreading mechanism and an adjustable needle guard to prevent stitch skipping. The thread clamp mechanism, tension release mechanism and needle thread draw-out mechanism enable the machine to leave thread of a uniform length after thread trimming, and prevent slip-off of the needle thread. All of these mechanisms contribute to upgraded sewing.

Safety stitching or reverse feed stitching with a simple lever operation

Safety stitching (condensation stitching) the perfect method of preventing loose stitches, or reverse feed stitching (back-tacking) can be alternated through the simple adjustment of the stopper of the reverse feed lever. Either sewing method can be used.

Beautifully finished seams

Provided with a sliding presser foot and a silicone oil lubricating unit as standard, stitch skipping and puckering are prevented. Furthermore, the silicone oil lubricating unit prevents the needle from overheating, and allows foundation yarn or synthetic thread to be used without breakage during sewing. These features assure beautifully finished seams with consistency for light- to medium-weight materials.

APPLICATION FOR MH-481 SERIES

Application Details
Men's Shirts Attaching yokes on the back
Slacks, pantaloons, ski pants Attaching Wait Belts, joining sides, seam insides, or hip seams
Coats, blazers Sewing the center of the back, joining sides, sewing sleeves, belts, collars, and sewing the facing on to the front.
Skirts Sewing the center and joining sides
One-piece suits, blouses, negligees Making pleats or gathers
Uniforns, jumpers Sew side and sew interlining on the wrong side of the materials
interior Decorations Making pleats or gathers

Technical Specification

Model name Juki MH-481-54U
Feed system Bottom-feed
Max. sewing speed 5,500rpm
Stitch length 1~4mm
Top-feed amount -
Differential-feed ratio -
Lift of the presser foot By hand: 5mm, By knee: 10mm
Needle bar stroke 30mm
Needle TV × 7 (#11) #9~#18
Stitch length adjustment By dial
Safety stitch Condensation stitch/reverse stitching (by feed lever)
Looper system Inclined crank
Looper stroke 21.5mm
Looper stroke of the front and rear 2.1~3.3mm
Speed control *(1)
Lubrication Automatic
Lubricating oil JUKI New Defrix Oil No.1 (equivalent to ISO VG7)
Motor output 750W
Power requirement Single-phase, 3-phase
Power consumption Rating 425VA

*"sti/min" stands for "Stitches per Minute."
*(1) From 500rpm to the Max. sewing speed determined by the pulley used (externally adjustable)

More Information

Part No JUKIMH48154U
Weight (KG) 0.100000
Manufacturer Juki
